Pioneer Inverter Pool Heat Pump.

The BWT Pioneer Inverter range offers a wide range of power to equip the 18 to 95 m3 pools and operates only in heating mode.

Pioneer Inverter Heat Pump - BWT
The Pioneer Inverter range of heat pumps offers a wide range of models equipped with Inverte technology.

Pioneer Inverter Heat Pumps System
The Inverter heat pump compressor can vary from 25% to 100% of its power depending on operating conditions and outside temperature, in contrast to traditional heat pumps that operate at constant speed (100%).

The Pioneer Inverter heat pump works 3 choices of heating mode: low, medium and high. Once the mode is selected and depending on the outside temperature, the Pioneer Inverter BWT heat pump will automatically speed up its compressor.

Benefits
Works at air temperatures of 0 to 35 degrees Celsius (depending on humidity) and thus prolongs the pool season. Inverter heat pumps also provide an average C.O.P. of 9 under the following operating conditions: Air 26oC, Water 26C, Humidity 80%.

Digital Regulator
High- and low-pressure controllers, water-free (flow switch), cycle inversion de-icing system and 5 temperature probes are controlled by a digital regulator that provides optimal heat pump protection and precise control of the pool temperature.

Pioneer Inverter Heat Pump Body
The body of the BWT Pioneer heat pumps is made of galvanized steel, coated with polymer protection, and this anti-corrosion protection is more durable and more efficient.

silence
A traditional "On/Off" heat pump always delivers the same level of acoustic power, even when it evolves around the set point. On the other hand, a Pioneer Inverter BWT heat pump will slow down near the set point, and will then generate only a low noise level compared to that of a traditional "On/Off" machine.

This argument is very important in the event that the heat pump is to be installed at fable distance from the neighbors. To this end, the attention of installers is drawn to the provisions of Decree No. 2006-1099 of 31 August 2006, relating to the fight against neighbourhood noise and amending the public health code (regulatory provisions).

Pioneer Inverter BWT Heat Pump Features:
Recommended pool volume (m3): 18-35
Operating temperature range:0-43
Heating power: Air at 26 degrees Celsius, water at 26 degrees Fahrenheit
Returned power (kW): 8.0
C.O.P:9.1-5.6
C.O.P at 50% speed: 8.0
Certified heating power: Air at 15degrees, Water at 26 degrees Celsius
Returned power (in kW): 6.0
C.O.P:5.9-4.1
C.O.P at 50% speed: 5.9
Rated power (in kW): 1.4
Nominal Entry Current (A): 9.5
Power cable section (mm2): 3x1.5
Tension: 220-240 V /monophasé / 50 Hz
Recommended water flow (m3/h): 2 to 4
Acoustic pressure at 1 m dB (A): 40.8 / 51.1
Sound pressure of 50% capacity at 1m dB (A): 43.9
Acoustic pressure at 10 m dB (A): 20.8 / 31.1
Interchange: PVC titanium spiral tube
Body: Metal case with plastic coating
Rated air input power 15oC (kW): 0.34-1.4
Rated air entry current 15oC (A): 1.48-6.0
Maximum entry current (A): 8.0
Hydraulic connection (mm): 50
Dimensions (LxPxH): 954 x 359 x 648
Inch dimensions: 375.59" x 141.33" x 255.11"
Net weight / Gross weight (kg): 46
Pioneer Inverter Heat Pump Guarantee
Heat pump: 2-year warranty
Titanium Interchange: 5-year warranty
Compressor: 5-year warranty
