Robot pool Zodiac R3

Robot pool Zodiac R3.
The robot pool cleaner Zodiac R3 is a novelty! This pool robot is ideal for small and medium size pools. Thanks to its new "Diaphragm Dia Cyclone" technology it is 40% more powerful than his colleagues for the cleaning of the bottom and the walls of your pool!

Strong points.
Technology diaphragm Dia Cyclone
Cleans bottom and walls
Pipes Twist Lock: easy and secure connection

Made in France, the R3 of Zodiac pool cleaner, designed to pool funds, is a new generation of hydraulic suction robot that includes a new exclusive and patented technology by the Zodiac brand: the diaphragm Dia Cyclone, making it 40% more powerful than the other models.

For what type of pool is robot Zodiac R3 recommended?
Types of pool: private ground pools and above ground to hard-sided pools
Recommended maximum size: 9 x 5 m
Pelvis shapes: rectangular, oval
Fund: flat, gentle slope
All coatings: tiles, liner, polyester, PVC armed, hull painted concrete
10 meters of hose supplied

Cleaning modes
The Zodiac R3 must be connected directly to decision-making broom or the skimmer. The water is sucked into the cleaner and dirt and debris are trapped by the filter of your pool system. After turn-on, it is advisable to let the robot do filtration in 6 hours (3 times 2 h) so that the bottom of your pool is perfectly clean.

Don't forget safety!
System of pipes to draw which allows connection easy and very secure the pipes with a high suction performance.

What does a robot of hydraulic pool?
Also called pool vacuum broom, the hydraulic robot plugs directly into the filtration system of the pool through the skimmer or broom making. The robot of hydraulic pool sucks dirt at the bottom of the basin, whatever its form. The hydraulic robot is the most affordable pool robots and can accommodate all types of pool.

Contents of the box.
Flow Tester
Automatic flow control valve
Wheel anti-blocages
Pipes Twist Lock
DIA Cylcone

Technical characteristics.
Robot type: hydraulic
Dimensions: 41 x 36 x 28 cm
Weight: 1.18 kg
Pools: above-ground, buried
Pool shape: rectangular, oval / round
Bottom of pool: gentle slope, flat
Pool length: 9 m
Type of cleaning: bottom, walls
Flooring: Tiles, Liner, polyester hull, armed, PVC painted concrete
Minimum pump power: 1/2 HP
Length of hose: 10 m (10 x 1 m)
Type of move: random
Cleaning width: 30 cm
Duration of cycles: 6 h Filtration recommended 3 times 2 hours
Movement speed: 6.5 m/min
Ability of filtration: filtration of the pool Circuit
The water line cleaning: no
Cleaning of the walls: Yes
Smartphone app / Tablet: no
Special functions: mechanical Aspiration: diaphragm Dia Cyclone
Warranty: 2 years

This high-quality article is a selection of the equipment for pools and Fitness specialist FitMarina.
